Magcubic HY300X

Image Magcubic HY300X
Customer review
Offer Ads
Discover the projector on Amazon. Now!
Model Overview Designed for the Game-Portabel sector, the HY300X model from Magcubic features 200 ANSI lumens, a native HDTV 1280 x 720 resolution and a contrast ratio of 8000:1. The manufacturer specifies a durability of 30000 hours for the LED light source, which translates to 20.5 years with 4 hours of daily use.
For basic image adjustment, the device is equipped with horizontal and vertical keystone correction, allowing digital compensation for trapezoidal distortion at angled projection setups.
Looking at practical performance, up to 144 cm can be illuminated with 200 ANSI lumens in dark environments. Once daylight is in the room, the image should ideally be no wider than 96 cm.
For media input, video signals up to 1080P and 4K are supported. Also on board is a local media player that allows reading and playing content directly from storage media. Furthermore, the model is Bluetooth-enabled, allowing audio signals to be sent wirelessly to external speakers. Thanks to support for Miracast and Airplay, screen content can also be cast wirelessly from a smartphone, tablet, or PC to the screen.
Regarding noise emissions, the model proves to be exceptionally quiet during operation, producing just 25 decibels.
Display Type 1 x LCD TFT Panel
HDTV 16/9 Liquid Crystal Display
Ansi-Lumen
Projector
200
Screen
89 Lux (200 cm Screen width)
Contrast 8000:1 full on/off 8000:1 full on/off
Black Level 0,0250 min. Lumen 0,011 min. Lumen
Offset 0,0% Centre of the screen →
SCREEN
+ Projector
Resolution HDTV 1280 x 720
921.600 Pixel
UHD (4K2K) 3840 x 2160 compressed
Video Modes Pal, SECAM, NTSC, HDTV 720p, 1080i, 1080p, 4K UHD (komprimiert), EDTV 480p, 576p
Media player formats: Mediaplayer
Application Game-Portabel | Very portable, small-screen projections.
Very narrow picture width and rooms with very little light.
Light Source LED
Light Life 30000 h.
Operating Costs 0,00 € LED
The projection is too dark.
The screen width should be reduced.
160 cm (no Zoom)
Lux: 89 Lux
Contrast: 8000:1
Candela pro m²: 27 cd/m²
Foot-Lamberts: 8 fL
0 cm

Screen width:cm
          Room:
•
Focus Powered
Zoom No Zoom 80%-100% Digital
Objective -
Throw Ratio 0,8:1
Audio 1 x 5W
Connections HDMI in
USB in
Audio Mini Jack out
Bluetooth 5.0
Ceiling Mounting Yes, is possible.
Size WxHxD 102 x 178 x 102 mm (4"x7"x4") 1,85 L/dm³
Power 40W
Keystone
Key: 43 cm

Key: 43 cm
+
+
SCREEN

Key: 43 cm
Key: 43 cm

Operating Noise 25dB
Weight 0,483 kg / 0 lbs.
Keystone Vert.: +/-15°  automatisch
Hori.: +/-15°
Illumination 60%
Frequenz -
Foot-Lamberts 8 fL / max. 144 cm screen width
Candela m² 27 cd/m²
Features Lens Shift Function geschätzt
Integrated Media Player
Automatic and Manual Vertical Keystone Correction
W-Lan Netzwerk kompatibel.
Short Throw Projector
Android 11.0
Google Voice Assistance
180? rotatable
4P Keystone
Screen Mirroring Miracast, Airplay
In Comparison
The Magcubic HY300X compared to others current "Game-Portabel" projectors.
Ansi-Lumen:
1 Weight:
70
Contrast:
1 dB:
88
Black level:
98 Power cons.:
100
Picture Total Points:33 Projector Total Points:86
Popularity Top 100
6 popularity points in May 5 popularity points in June 10 popularity points in July 13 popularity points in August 10 popularity points in September 16 popularity points in October
Points:
16
Ranking: 183 (From: 614)
Live-Trend (Last 3 days)   LiveLIVE
Points: 7 -9% Trend
Status 2025 Current model // Last update of the data: 2026-10-23
Created:
Data
Product Sheet english HC
User Manual english (14.58 MB)
