O.B.E Oray Plus

Image O.B.E Oray Plus
Customer review
Offer Ads
Discover the projector on Amazon. Now!
Model Overview As a projector for the Standard-Portabel sector, the O.B.E Oray Plus is equipped with 1000 ANSI lumens, a HDTV 1920 x 1080 resolution and a contrast of 3000:1. The built-in LED technology features a light source lifespan of 20000 hours – equivalent to a usable life of 13.7 years at 4 hours a day.
Should a perpendicular setup to the screen not be possible, the integrated keystone correction (horizontal and vertical) helps to realign the image into a perfect rectangle.
To make performance data comparable based on the ISO lumen values, we calculated an approximate ANSI lumen value. Regarding projection size, the value of 1000 ANSI lumens allows for an image width of up to 321 cm in darkened environments. In rooms with ambient light, the image width should be correspondingly reduced to a maximum of 214 cm. Additionally, a built-in ambient light sensor measures the room lighting and automatically adjusts the projection settings.
For media input, video signals up to 1080P are supported. With the Google TV operating system, the projector acts as a media hub with centralized access to various apps. Furthermore, the model is Bluetooth-enabled, allowing audio signals to be sent wirelessly to external speakers. Thanks to support for Miracast and Airplay, screen content can also be cast wirelessly from a smartphone, tablet, or PC to the screen.
Display Type 1 x 4,45" LCD TFT Panel
HDTV 16/9 Liquid Crystal Display
Ansi-Lumen
Projector
~1000 / 800 ISO Lumen
Screen
444 Lux (200 cm Screen width)
Contrast 3000:1 full on/off 3000:1 full on/off
Black Level 0,3333 min. Lumen 0,148 min. Lumen
Offset 0,0% Centre of the screen →
SCREEN
+ Projector
Resolution HDTV 1920 x 1080
2.073.600 Pixel
Video Modes Pal, SECAM, NTSC, HDTV 720p, 1080i, 1080p, EDTV 480p, 576p
Application Standard-Portabel | External training and company presentations, as well as product presentations.
Small screen width, rooms with very little ambient light below 50 lumens.
Light Source LED
Light Life 20000 h.
Operating Costs 0,00 € LED
Calculated brightness quality Good (1.8)
240 cm (no Zoom)
Lux: 444 Lux
Contrast: 3000:1
Candela pro m²: 140 cd/m²
Foot-Lamberts: 41 fL
0 cm

Screen width:cm
          Room:
•
Focus Automatic
Zoom No Zoom
Objective -
Throw Ratio 1,2:1
Audio 2 x 10W
Connections 2x HDMI in
Mini Jack Audio out
USB-A in
Bluetooth 5.4
Ceiling Mounting Yes, is possible.
Size WxHxD -
Power -
Keystone

+
+
SCREEN

Operating Noise -
Weight -
Keystone Vertical automatic and horizontal
Illumination 60%
Frequenz -
Foot-Lamberts 41 fL / max. 321 cm screen width
Candela m² 140 cd/m²
Features Full HD 1080P
Lens Shift Function geschätzt
Automatic and Manual Vertical Keystone Correction
W-Lan Netzwerk kompatibel.
Ambient Light Sensor
VIDAA Smart TV or Google TV
Auto 4P Keystone
Screen Mirroring Miracast, Airplay, Windows
In Comparison
The O.B.E Oray Plus compared to others current "Standard-Portabel" projectors.
Ansi-Lumen:
12 Weight: -
Contrast:
1 dB: -
Black level:
96 Power cons.: -
Picture Total Points:36 Projector Total Points:-
Popularity Top 100
0 popularity points in May 0 popularity points in June 0 popularity points in July 1 popularity points in August 9 popularity points in September 14 popularity points in October
Points:
14
Ranking: 160 (From: 1044)
Live-Trend (Last 3 days)   LiveLIVE
Points: 9 -5% Trend
Status 2026 Current model // Last update of the data: 2026-10-23
Created:
Data
Product Sheet english HC

Projektor O.B.E Oray Plus Projektor O.B.E Oray Plus Projektor O.B.E Oray Plus Projektor O.B.E Oray Plus
