Zoomcat E1

Image Zoomcat E1
Customer review
Offer Ads
Discover the projector on Amazon. Now!
Model Overview Categorized in the Standard-Portabel segment, the E1 projector from Zoomcat projects with a HDTV 1920 x 1080 resolution, alongside 800 ANSI lumens and a contrast of 20000:1. The built-in LED technology features a light source lifespan of 30000 hours. Daily use of 4 hours makes an operational lifespan of over 20.5 years possible.
For basic image adjustment, the device is equipped with horizontal and vertical keystone correction, allowing digital compensation for trapezoidal distortion at angled projection setups.
A look at the light output reveals: The 800 ANSI lumens are sufficient to illuminate an image width of up to 287 cm in darkened rooms. If room light is present, we recommend not exceeding a maximum width of 191 cm.
In terms of video signals, the device processes resolutions up to Full HD 1080P and 4K. Furthermore, the model is Bluetooth-enabled, allowing audio signals to be sent wirelessly to external speakers. Since the projector supports Miracast and Airplay screen mirroring, video signals can also be streamed wirelessly from the end device.
Display Type 1 x LCD TFT Panel
HDTV 16/9 Liquid Crystal Display
Ansi-Lumen
Projector
800
Screen
356 Lux (200 cm Screen width)
Contrast 20000:1 20000:1
Black Level 0,0400 min. Lumen 0,018 min. Lumen
Offset 0,0% Centre of the screen →
SCREEN
+ Projector
Resolution HDTV 1920 x 1080
2.073.600 Pixel
UHD (4K2K) 3840 x 2160 compressed
Video Modes Pal, SECAM, NTSC, HDTV 720p, 1080i, 1080p, 4K UHD (komprimiert), EDTV 480p, 576p
Application Standard-Portabel | External training and company presentations, as well as product presentations.
Small screen width, rooms with very little ambient light below 50 lumens.
Light Source LED
Light Life 30000 h.
Operating Costs 0,00 € LED
Calculated brightness quality Good (2.1)
250 cm (no Zoom)
Lux: 356 Lux
Contrast: 20000:1
Candela pro m²: 113 cd/m²
Foot-Lamberts: 33 fL
0 cm

Screen width:cm
          Room:
•
Focus Powered
Zoom No Zoom 50%-100% Digital
Objective -
Throw Ratio 1,25:1
Audio -
Connections HDMI in
Mini Jack Audio out
USB in
Bluetooth 5.3
Ceiling Mounting Yes, is possible.
Size WxHxD 200,7 x 83,8 x 195,6 mm (7,9"x3,3"x7,7") 3,24 L/dm³
Power 70W
Keystone

+
+
SCREEN

Operating Noise -
Weight -
Keystone Vertical and horizontal
Illumination 60%
Frequenz -
Foot-Lamberts 33 fL / max. 287 cm screen width
Candela m² 113 cd/m²
Features Full HD 1080P
Lens Shift Function geschätzt
W-Lan Netzwerk kompatibel.
Android 13.0
Netflix Certified
Auto 6D Keystone
Screen Mirroring Miracast, Airplay, Windows
In Comparison
The Zoomcat E1 compared to others current "Standard-Portabel" projectors.
Ansi-Lumen:
9 Weight: -
Contrast:
1 dB: -
Black level:
100 Power cons.:
100
Picture Total Points:37 Projector Total Points:-
Popularity Top 100
5 popularity points in May 15 popularity points in June 13 popularity points in July 13 popularity points in August 12 popularity points in September 12 popularity points in October
Points:
12
Ranking: 223 (From: 1044)
Live-Trend (Last 3 days)   LiveLIVE
Points: 7 -5% Trend
Status 2025 Current model // Last update of the data: 2026-11-01
Created:
Data
Product Sheet english HC
User Manual english (8.81 MB)
