Behind the name HDS 1600 is a LCD projector by Suant, whose main features include 1600 ANSI lumens, a contrast of 600:1 and a SVGA 800 x 600 resolution. The manufacturer specifies a runtime of 6000 hours for this projector's lamp, achieving a lifespan of 8.2 years when used for 2 hours a day. Looking at practical performance, up to 348 cm can be illuminated with 1600 ANSI lumens in dark environments. Once daylight is in the room, the image should ideally be no wider than 232 cm. The projector was released in 2009 and is officially no longer distributed by Suant.
Display Type
1 x LCD TFT Panel SVGA 4/3 Liquid Crystal Display
Ansi-Lumen
Projector
1600
Screen
533 Lux (200 cm Screen width)
Contrast
600:1 full on/off
600:1 full on/off
Black Level
2,6667 min. Lumen
0,893 min. Lumen
Offset
-
Resolution
SVGA 800 x 600
480.000 Pixel SXGA 1280 x 1024 compressed
Video Modes
PAL, SECAM, NTSC,
Application
Standard-Portabel | External training and company presentations, as well as product presentations. Small screen width, rooms with very little ambient light below 50 lumens.
Light Source
-
Light Life
6000 h.
Operating Costs
-
Calculated brightness quality Perfect
Lux:
533 Lux
Contrast:
600:1
Candela pro m²:
171 cd/m²
Foot-Lamberts:
50 fL
•
Focus
Manual
Zoom
No Zoom
Objective
f=170mm
Throw Ratio
-
Audio
-
Connections
HDMI 1.3
D-sun 15 pin in
YUV in
S-Video in
Cinch Video in
I am looking for a Remote control for my SUANT HDS1600 Projektor. Where van I buy a replace one or did someone know a working universal type number that Will work with this beamer.
Autor:
thekla 07.11.11
1
Star
user manual in german
hello, i need a german user manual for the HDS 1600, how do i get the???? I can‘t give any more points because I don‘t have an instruction manual
Autor:
akkoc 22.06.09
1
Star
hello
I bought it today and wanted to know how much it costs and whether it‘s any good
