VISULAPEX NX3


Netflix Zertifiziert
Image VISULAPEX NX3
Customer review
Offer Ads
Discover the projector on Amazon. Now!
Model Overview The technical data of the VISULAPEX NX3 includes 600 ANSI lumens, a contrast of 15000:1 as well as a HDTV 1920 x 1080 display. The manufacturer specifies a durability of 30000 hours for the LED light source. Daily use of 4 hours makes an operational lifespan of over 20.5 years possible.
For basic image adjustment, the device is equipped with horizontal and vertical keystone correction, allowing digital compensation for trapezoidal distortion at angled projection setups.
Because the manufacturer specifies brightness in lumen specifications, we have determined an ANSI lumen value for better comparability. Regarding projection size, the value of 600 ANSI lumens allows for an image width of up to 305 cm in darkened environments. In rooms with ambient light, the image width should be correspondingly reduced to a maximum of 203 cm. Additionally, a built-in ambient light sensor measures the room lighting and automatically adjusts the projection settings.
Regarding signal processing, the model is compatible with incoming 1080P content as well as 3D. As an additional feature, an integrated media player enables the direct playback of files without an external source device. For wireless audio output, the projector also supports Bluetooth, making it easy to quickly connect external soundbars. For integration into professional environments, an RJ45 connection is available for network control and remote maintenance. Thanks to support for Miracast, Airplay and DLNA, screen content can also be cast wirelessly from a smartphone, tablet, or PC to the screen.
Regarding noise emissions, the model proves to be exceptionally quiet during operation, producing just 26 decibels.
Display Type 1 x LCD TFT Panel
HDTV 16/9 Liquid Crystal Display
Ansi-Lumen
Projector
~600 / 15000 Lumen
Screen
267 Lux (200 cm Screen width)
Contrast 15000:1 full on/off 15000:1 full on/off
Black Level 0,0400 min. Lumen 0,018 min. Lumen
Offset 0,0% Centre of the screen →
SCREEN
+ Projector
Resolution HDTV 1920 x 1080
2.073.600 Pixel
Video Modes Pal, SECAM, NTSC, HDTV 720p, 1080i, 1080p, 3D, EDTV 480p, 576p
Media player formats: Mediaplayer
3D Compatibility Frame-Packing (Full HD 3D) | Side-by-Side | Top-and-Bottom | Frame Sequential (3D Ready)
Application Standard-Portabel | External training and company presentations, as well as product presentations.
Small screen width, rooms with very little ambient light below 50 lumens.
Light Source LED
Light Life 30000 h.
Operating Costs 0,00 € LED
Calculated brightness quality Good (2.5)
250 cm (no Zoom)
Lux: 267 Lux
Contrast: 15000:1
Candela pro m²: 86 cd/m²
Foot-Lamberts: 25 fL
0 cm

Screen width:cm
          Room:
•
Focus Automatic
Zoom No Zoom
Objective -
Throw Ratio 1,25:1
Audio 2 x 5W
Connections HDMI 2.0 in
USB-A 2.0 in
Mini Jack Audio out
RJ45
Bluetooth 5.1
Ceiling Mounting -
Size WxHxD 180 x 190 x 135 mm (7,1"x7,5"x5,3") 4,62 L/dm³
Power 120W
Keystone
Key: 91 cm

Key: 91 cm
+
+
SCREEN

Key: 91 cm
Key: 91 cm

Operating Noise 26dB
Weight 1,69 kg / 2,2 lbs.
Keystone Vert.: +/-20°  automatisch
Hori.: +/-20°
Illumination 60%
Frequenz -
Foot-Lamberts 25 fL / max. 305 cm screen width
Candela m² 86 cd/m²
Features Real Full HD 3D
Full HD 1080P
Lens Shift Function geschätzt
Integrated Media Player
Automatic and Manual Vertical Keystone Correction
High Dynamic Range (HDR)
W-Lan Netzwerk kompatibel.
Lan Netzwerk kompatibel.
Ambient Light Sensor
Android 6.0
Screen Mirroring Miracast / AirPlay / DLNA / Eshare
In Comparison
The VISULAPEX NX3 compared to others current "Standard-Portabel" projectors.
Ansi-Lumen:
6 Weight:
97
Contrast:
1 dB:
85
Black level:
100 Power cons.:
94
Picture Total Points:36 Projector Total Points:92
Popularity Top 100
1 popularity points in May 2 popularity points in June 3 popularity points in July 3 popularity points in August 2 popularity points in September 7 popularity points in October
Points:
7
Ranking: 500 (From: 1044)
Live-Trend (Last 3 days)   LiveLIVE
Points: 3 -4% Trend
Status 2023 Current model // Last update of the data: 2026-11-01
