The basic data of the Boxlight XP 680i includes 1500 ANSI lumens, a resolution of XGA 1024 x 768 as well as a contrast of 500:1. The manufacturer lists the lamp life at 2000 hours. Looking at practical performance, up to 337 cm can be illuminated with 1500 ANSI lumens in dark environments. Once daylight is in the room, the image should ideally be no wider than 225 cm. Since entering the market in 2006, production has been discontinued; the manufacturer no longer actively offers the model.
Display Type
3 x 0,6" LCD TFT Panel mit MLA XGA 4/3 Liquid Crystal Display with Micro Lense Array
Ansi-Lumen
Projector
1500 / 1200 im Eco Mode
Screen
500 Lux (200 cm Screen width)
Contrast
500:1 full on/off
500:1 full on/off
Black Level
3,0000 min. Lumen
1,006 min. Lumen
Offset
35,7% 21 cm under screen top edge →
SCREEN
+Projector
Resolution
XGA 1024 x 768
786.432 Pixel SXGA 1280 x 1024 compressed
Standard-Portabel | External training and company presentations, as well as product presentations. Small screen width, rooms with very little ambient light below 50 lumens.
Eco Mode
Boxlight Website
Product Sheet english HC
