Dukane ImagePro 8407

Image Dukane ImagePro 8407
Customer review
Offer Ads
Discover other popular projectors on Amazon!
Model Overview The projector ImagePro 8407 by Dukane utilizes DLP technology and, according to the spec sheet, achieves 3600 ANSI lumens, a contrast of 2500:1 at a resolution of WXGA 1280 x 800. The manufacturer rates the durability of the included lamp at 2000 hours.
Looking at practical performance, up to 610 cm can be illuminated with 3600 ANSI lumens in dark environments. Once daylight is in the room, the image should ideally be no wider than 407 cm.
For media input, video signals up to 1080P are supported. For integration into professional environments, an RJ45 connection is available for network control and remote maintenance.
This model dates back to 2010 and is no longer part of Dukane's current product range.
Display Type 1 x 0,65" DLP Chip
WXGA 16/10 Ti Digital Light Processing Chip
Ansi-Lumen
Projector
3600
Screen
1440 Lux (200 cm Screen width)
Contrast 2500:1 full on/off 2500:1 full on/off
Black Level 1,4400 min. Lumen 0,577 min. Lumen
Offset 70% 25 cm over screen top edge →
SCREEN
+ Projector
Resolution WXGA 1280 x 800
1.024.000 Pixel
UXGA 1600 x 1200 compressed
Video Modes PAL, SECAM, NTSC, HDTV 720p, 1080i, 1080p EDTV 480p, 576p
Application Standard-Portabel | External training and company presentations, as well as product presentations.
Medium screen width or rooms with a little more ambient light, max. 200 lumens.
Light Source 280W Lamp
Light Life 2000 h. 3000 h. in Eco Mode
Operating Costs -
Calculated brightness quality
The screen width may also be larger. Perfect
304 - 350 cm
Lux: 1440 Lux
Contrast: 2500:1
Candela pro m²: 459 cd/m²
Foot-Lamberts: 134 fL
88 cm


Screen width:cm
          Room:
•
Focus Manual
Zoom Manual 1,15
Objective F=2,57-2,77 f=21,3-24,5 mm
Throw Ratio 1,52-1,75:1 show
Audio -
Connections DVI-I mit HDCP in
D-sub 15 pin in
S-Video in
Cinch Video in
Mini Jack Audio in und out
12V Trigger out
RS232C
RJ45 in
Ceiling Mounting Yes, is possible.
Size WxHxD 300 x 100,5 x 244 mm (11,8"x4"x9,6") 7,32 L/dm³
Power 350W / 5W standby
Keystone
Key: 264 cm

Not
possible
+
+
SCREEN

Not
possible
Key: 88 cm

Operating Noise 32 / 30 dB in Eco Mode
Weight 3,70 kg / 8,16 lbs.
Keystone Vert.: +/-30°
Illumination 85%
Frequenz H-sync: 15-90 kHz
V-sync: 50-85 Hz
Foot-Lamberts 134 fL / max. 610 cm screen width
Candela m² 459 cd/m²
Features Eco Mode
Kensington Slot
Password Protection
BrilliantColor™
Remote Control with Laser Pointer
Lan Netzwerk kompatibel.
Screen Mirroring Optional only Google TV / Fire TV / Apple TV / Roku TV / Xiaomi TV Ads
In Comparison
The Dukane ImagePro 8407 compared to others not current "Standard-Portabel" projectors.
Ansi-Lumen:
51 Weight:
65
Contrast:
34 dB:
44
Black level:
25 Power cons.:
61
Picture Total Points:37 Projector Total Points:57
Popularity Top 100
0 popularity points in May 1 popularity points in June 3 popularity points in July 3 popularity points in August 7 popularity points in September 6 popularity points in October
Points:
6
Ranking: 4245 (From: 7741)
Live-Trend (Last 3 days)   LiveLIVE
Points: 6 ±0% Trend
Optional accessories
ceiling bracket length: 100-120mmHalterung10047,86 €
Status 2010 Discontinued (EOL) // Last update of the data: 2026-06-09
