The PJD7583wi model from Viewsonic combines DLP technology in the Short Distance sector with 3000 ANSI lumens, a contrast of 3000:1 and a native WXGA 1280 x 800 resolution. In operating mode, the installed projector lamp offers a lifespan of 4000 hours. A daily usage of 2 hours makes an operational lifespan of 5.5 years possible. With its built-in wide-angle optics, the device belongs to the category of short-throw projectors. An image width of 2 meters is realized from a short distance of 100 cm. Regarding projection size, the value of 3000 ANSI lumens allows for an image width of up to 556 cm in darkened environments. In rooms with ambient light, the image width should be correspondingly reduced to a maximum of 371 cm. For media input, video signals up to 1080P are supported. Also on board is a local media player that allows reading and playing content directly from storage media. For convenient remote monitoring and administration, the projector is equipped with a classic RJ45 network socket. This model dates back to 2010 and is no longer part of Viewsonic's current product range.
Display Type
1 x 0,65" DLP Chip WXGA 16/10 Ti Digital Light Processing Chip
Ansi-Lumen
Projector
3000
Screen
1200 Lux (200 cm Screen width)
Contrast
3000:1 full on/off
3000:1 full on/off
Black Level
1,0000 min. Lumen
0,4 min. Lumen
Offset
55% 6 cm over screen top edge →
SCREEN
+Projector
Resolution
WXGA 1280 x 800
1.024.000 Pixel UXGA 1600 x 1200 compressed
Video Modes
PAL, SECAM, NTSC, HDTV 720p, 1080i, 1080p EDTV 480p, 576p Media player formats: JPEG,
BMP, TIFF, PNG, GIF
Disc Recognition
DVD | HD Blu-ray (komprimiert) | 3D Blu-ray | 4K UHD Blu-ray
3D Compatibility
Frame Sequential (3D Ready) |
Application
Short Distance | Medium screen width or rooms with a little more ambient light, max. 200 lumens.
Full HD 1080P compatible Integrated Mediaplayer Freeze Blackboard Modus Eco Mode Kensington Slot Password protection BrilliantColor™ Remote control with laser pointer und mouse control PJLink™ Control via web browser Lan network compatible. Short-throw projector Crestron®-Software compatible. 6-segment RGBCYW colour wheel
Full HD 1080P compatible
