Model Overview The x31 is a LCD projector by 3M, whose specifications list 2700 ANSI lumens, a contrast of 500:1 and a XGA 1024 x 768 resolution. The manufacturer lists the lamp life at 3000 hours.
Regarding projection size, the value of 2700 ANSI lumens allows for an image width of up to 453 cm in darkened environments. In rooms with ambient light, the image width should be correspondingly reduced to a maximum of 302 cm.
In terms of video signals, the device processes resolutions up to Full HD 1080P. For convenient remote monitoring and administration, the projector is equipped with a classic RJ45 network socket. Equipped with a microphone jack and built-in speakers (16W), audio signals during presentations can be played back directly without an external audio system.
This model dates back to 2010 and is no longer part of 3M's current product range.
Display Type 3 x 0,63" LCD TFT Panel
XGA 4/3 Liquid Crystal Display
Ansi-Lumen
Projector
2700 / 2000 im Eco Mode
Screen
900 Lux (200 cm Screen width)
Contrast 500:1 full on/off 500:1 full on/off
Black Level 5,4000 min. Lumen 1,811 min. Lumen
Offset 40% cm under screen top edge →
SCREEN
+ Projector
Resolution XGA 1024 x 768
786.432 Pixel
UXGA 1600 x 1200 compressed
Video Modes PAL, SECAM, NTSC, HDTV 720p, 1080i, 1080p, EDTV 480p, 576p
Application Standard-Portabel | External training and company presentations, as well as product presentations.
Medium screen width or rooms with little light, max. 100 lumens.
Light Source 210 / 140W im Eco Mode Lamp
Article Nr.: 78-6972-0008-3
Order Lamp
52,21 - 78,93 €
Light Life 3000 h. 6000 h. in Eco Mode
Operating Costs -
Calculated brightness quality Perfect
300 - 360 cm
Lux: 900 Lux
Contrast: 500:1
Candela pro m²: 288 cd/m²
Foot-Lamberts: 84 fL
60 cm

Screen width:cm
          Room:
•
Focus Manual
Zoom Manual 1,2
Objective F=1,67-1,91 f=19-23 mm
Throw Ratio 1,5-1,8:1 show
Audio 1 x 16W
Connections 2 x D-sub 15 pin in 1 x out
YUV in
S-Video in
Cinch Video in
Cinch Stereo in
Mini Jack Audio in
Mini Jack Mikrofon in
USB in
RS232C Din 9 pin in
RJ45 in
Ceiling Mounting Yes, is possible.
Size WxHxD 317 x 98 x 288 mm (12,5"x3,9"x11,3") 8,95 L/dm³
Power 330W
Keystone
Key: 233 cm

Not
possible
+
+
SCREEN

Not
possible
Key: 113 cm

Operating Noise 37 / 30 dB in Eco Mode
Weight 3,60 kg / 7,94 lbs.
Keystone Vert.: +/-30°  automatisch
Illumination -
Frequenz H-sync: 31,5-106 kHz
V-sync: 56-120 Hz
Foot-Lamberts 84 fL / max. 453 cm screen width
Candela m² 288 cd/m²
Features Freeze
Blackboard Mode
Custom Logo Display
Eco Mode
Automatic and Manual Vertical Keystone Correction
Kensington Slot
Gamma Correction
Password Protection
PJLink™
Adjustable Overscan
Lan Netzwerk kompatibel.
Screen Mirroring -
In Comparison
The 3M x31 compared to others not current "Standard-Portabel" projectors.
Ansi-Lumen:
38 Weight:
67
Contrast:
20 dB:
31
Black level:
14 Power cons.:
64
Picture Total Points:24 Projector Total Points:54
Popularity Top 100
1 popularity points in May 2 popularity points in June 6 popularity points in July 6 popularity points in August 6 popularity points in September 10 popularity points in October
Points:
10
Ranking: 1894 (From: 7741)
Live-Trend (Last 3 days)   LiveLIVE
Points: 6 -4% Trend
Optional accessories
Osram bulb only NLMP1930661,26 €
lamp ruby Ruby-LMP1930678,93 €
lamp incl. air filter Original78-6972-0008-3 / DT01025EOL €
Compatible lamp LMP-K1930352,21 €
Universal Remote Fernb-uni-V322,31 €
air filter OriginalMU06481 & MU0643231,07 €
Ceiling Mount 100-120 Halterung10047,86 €
Status 2010 Discontinued (EOL) // Last update of the data: 2026-06-10
