The X120E model is a LCD projector from Mitsubishi, intended for Standard-Portabel applications, offering 1000 ANSI lumens, a contrast of 200:1 at XGA 1024 x 768. The manufacturer specifies a runtime of 2000 hours for this projector's lamp. Regarding projection size, the value of 1000 ANSI lumens allows for an image width of up to 275 cm in darkened environments. In rooms with ambient light, the image width should be correspondingly reduced to a maximum of 183 cm. As an additional feature, an integrated media player enables the direct playback of files without an external source device. This model dates back to 1999 and is no longer part of Mitsubishi's current product range.
XGA 1024 x 768
786.432 Pixel
SXGA 1280 x 1024 compressed
Video Modes
PAL,SECAM,NTSC,Composite Video,S-Video,DVD-Komponenten Media player formats: JPEG
Application
Standard-Portabel | External training and company presentations, as well as product presentations. Small screen width, rooms with very little ambient light below 50 lumens.
Video x 1: RCA component or S-Video
Audio x 1: Stereo RCA type
PC x 1: RGB mini D-sub 15pin;
Audio x 1: 3.5mm stereo mini jack
PCMCIA Flash memory slot x 1
Output Terminals PC x 1: RGB mini D-sub 15pin (VGA)
Audio: 3.5mm stereo mini jack
Communication Terminals RS232C port; PCGC (Graphical user interface control) through PC
Ceiling Mounting
Yes, is possible.
Power
250W
Size WxHxD
264 x 115 x 340 mm (10,4"x4,5"x13,4") 10,32 L/dm³
Operating Noise
38dB
Weight
4,50 kg / 9,92 lbs.
Keystone
-
Illumination
85%
Frequenz
H-sync: 15-82 kHz V-sync: 50-85 Hz Range max.: 140 MHz
Integrated Mediaplayer Gamma correction Remote control with laser pointer Crestron®-Software compatible. Built-in line doubler PC Card playback system via PCMCIA (1 slot)
Unfortunately, I no longer have an instruction manual for the old LVP X120e. Does anyone know whether there is a reset or a lamp operating hours counter? The LED flashes, but the lamp still lights up well.
