The technical data of the Optoma ZU606T-B includes 6000 ANSI lumens, a contrast of 2000:1 as well as a WUXGA 1920 x 1200 display. This is a laser projector with a light source designed to last for 20000 hours. With four hours of daily operation, this corresponds to a period of 13.7 years. The image geometry can be adjusted via the built-in keystone correction so that a clean, rectangular display is achieved even with non-ideal placement. A look at the light output reveals: The 6000 ANSI lumens are sufficient to illuminate an image width of up to 787 cm in darkened rooms. If room light is present, we recommend not exceeding a maximum width of 525 cm. In terms of video signals, the device processes resolutions up to Full HD 1080P and 4K as well as 3D. Furthermore, the model supports 360° projections for highly flexible deployment scenarios. Thanks to MHL support, screen content from mobile devices can be transmitted via cable, including charging power for the device. Regarding professional networking, the device offers a classic RJ45 LAN port for control alongside HDBaseT for the lossless transmission of picture and sound over long distances. Equipped with a microphone jack and built-in speakers (10W), audio signals during presentations can be played back directly without an external audio system. The projector was released in 2019 and is officially no longer distributed by Optoma.
Display Type
1 x 0,67" DLP Chip WUXGA 16/9 Ti Digital Light Processing Chip
Ansi-Lumen
Projector
6000
Screen
2667 Lux (200 cm Screen width)
Contrast
2000:1 full on/off
2000:1 full on/off
Black Level
3,0000 min. Lumen
1,335 min. Lumen
Offset
50% Exactly on screen top edge →
SCREEN
+Projector
Resolution
WUXGA 1920 x 1200
2.304.000 Pixel UHD (4K+2K) 4096 x 2160 compressed
Standard-Portabel | External training and company presentations, as well as product presentations. Very large screen width and rooms with plenty of light and shaded daylight.
2 x HDMI in (HDMI2.0 /HDMI1.4 MHL)
D-sub 15pin 2xin und out
Cinch Video in
S-Video in
Mini Jack Audio 2 in und out
Microphone
USB in
12VTrigger out
RS232C Din 9 pin in
RJ45 in
HDBaseT
Ceiling Mounting
Yes, is possible.
Power
406W / 188W in Eco Mode
Size WxHxD
373,4 x 116,8 x 302,3 mm (14,7"x4,6"x11,9") 13,07 L/dm³
Real Full HD 3D Full HD 1080P compatible Eco Mode Kensington Slot High Dynamic Range (HDR) 360° installable BrilliantColor™ PJLink™ Optional Wi-Fi network compatible. Lan network compatible. Crestron®-Software compatible.
Real Full HD 3D
